52311A DAC200-6-H3 Centrifugal Air Compressor
Tag No: 52311A
Model: DAC200-6-H3
Name: Centrifugal Air Compressor
1. 空压机技术参数
Technical parameters of gas compressor
|
序号 SN |
项目 Item |
单位 Unit |
额定技术参数 Rated technical parameters |
|
1.1 |
压缩机型号 Compressor model |
- |
DAC200-6-H3 |
|
1.2 |
压缩介质 Compressed medium |
- |
空气 |
|
1.3 |
压缩级数 Compression level |
- |
3 |
|
1.4 |
数量 Qty |
台 |
2 |
|
1.5 |
大气压力 Atmospheric pressure |
KPa G |
97.59 |
|
1.6 |
进气压力 Inlet gas pressure |
KPa G |
95.59 |
|
1.7 |
设计进气温度 Designed inlet gas temperature |
℃ |
35 |
|
1.8 |
设计相对湿度 Designed relative humidity |
% |
70 |
|
1.9 |
设计进气流量 Designed inlet gas flow |
Nm³/min(20℃标) |
135 |
|
1.10 |
设计工况流量 Designed operating flow |
m³/min |
150 |
|
1.11 |
排气压力 Outlet gas pressure |
Bar G |
6 |
|
1.12 |
压缩机轴功率 Compressor shaft power |
kW |
740 |
|
1.13 |
主电机额定功率 Rated power of main motor |
kW |
800 |
|
1.14 |
排气温度 Outlet gas temperature |
≥℃ |
110 |
|
1.15 |
冷却水进口温度 Cooling water inlet temperature |
≤℃ |
32 |
|
1.16 |
冷却水给水压力 Cooling water supply pressure |
MPa |
0.35~0.5 |
|
1.17 |
冷却水耗量 Cooling water consumption |
T/h |
81 |
|
1.18 |
润滑油量 Lubricant quantity |
L |
360 |
|
1.19 |
污垢系数 Fouling Factor |
m2.h. ℃/Kcal |
0.0004 |
|
1.20 |
噪声 Noise |
dB(A) |
≤85 |
|
1.21 |
调节范围 Adjustment range |
% |
70～100 |
|
1.22 |
排气含油量 Oil content of outlet gas |
|
100%无油（已通过TUV 0级无油认证） 100% oil-free (certified as TUV Level 0 oil-free) |
|
1.23 |
中压电源条件 Medium voltage power supply conditions |
电压/频率 Voltage/Frequency |
6kV/50Hz |
|
1.24 |
低压电源条件 Low voltage power supply conditions |
电压/频率 Voltage/Frequency |
380V/50Hz |
|
1.25 |
压缩机组重量 Weight of compressor unit |
kg |
~11000 |
|
1.26 |
外型尺寸L×W×H Dimensions L × W × H |
mm |
~3750*2180*2700 |
2. 离心机配置清单
Centrifuge configuration list
|
压缩机本体包括 The compressor body includes |
|||
|
序号 SN |
内容 Content |
数 量 Qty |
生 产 商 Manufacturer |
|
2.1 |
齿轮箱 Gearbox |
1 |
|
|
2.2 |
整体机壳 Single-piece frame |
1 |
|
|
2.3 |
叶轮 Vane |
3 |
|
|
2.4 |
扩压器 Compressor expander |
3 |
|
|
2.5 |
迷宫式气密封 Maze type gas seal |
3 |
|
|
2.6 |
油密封 Oil seal |
4 |
|
|
2.7 |
可倾瓦高/低速轴承 Tilting pad high/low-speed bearings |
4 |
|
|
2.8 |
主轴轴承 Spindle bearing |
2 |
|
|
2.9 |
进口调节导叶（带执行机构和定位器） Imported regulating guide vane (with actuator and locator) |
1 |
|
|
2.10 |
级间管道 Inter stage pipeline |
1 |
|
|
气体冷却器包括 Gas cooler includes |
|||
|
序号 SN |
内容 Content |
数 量 Qty |
生 产 商 Manufacturer |
|
2.11 |
中间冷却器 Intercooler |
2 |
|
|
2.12 |
后部冷却器 Rear cooler |
/ |
local sourcing |
|
2.13 |
自动/手动放水阀 Automatic/manual drain valve |
3 |
|
|
润滑油系统包括 The lubricating oil system includes |
|||
|
序号 SN |
内容 Content |
数 量 Qty |
生 产 商 Manufacturer |
|
2.14 |
油箱（带油位镜） Oil tank (with oil stage gauge) |
1 |
|
|
2.15 |
主油泵 Main oil pump |
1 |
HELNCO |
|
2.16 |
辅助油泵（启动器位于电控箱内） Auxiliary oil pump (starter located in the electrical control box) |
1 |
HELNCO |
|
2.17 |
10微米级油过滤器 10 micron oil filter |
1 |
MANN |
|
2.18 |
油冷却器 Oil cooler |
1 |
|
|
2.19 |
油压控制阀 Oil pressure control valve |
1 |
AFS or equal |
|
2.20 |
油温控制器 Oil temperature controller |
1 |
AMOT or equal |
|
2.21 |
油管路、管件 Oil pipelines and fittings |
1 |
|
|
2.22 |
油加热器 oil heater |
1 |
HEATER |
|
2.23 |
电动排风油箱呼吸器 Electric exhaust oil tank respirator |
1 |
|
|
2.24 |
首次运行润滑油 First operation of lubricating oil |
1 |
|
|
仪表控制系统包括 The instrument control system includes |
|||
|
序号 SN |
内容 Content |
数 量 Qty |
生 产 商 Manufacturer |
|
2.25 |
微电脑控制器PLC Microcomputer controller PLC |
1 |
SIEMENS |
|
2.26 |
人机界面HMI Human Machine Interface (HMI) |
1 |
SIEMENS |
|
2.27 |
低压电控箱，包括各种启动器、接触器、断路器及变压器等，以上设备在厂内即已安装好并已接线 Low voltage electrical control box, including various starters, contactors, circuit breakers, transformers, etc., which have been installed and wired in the factory |
1 |
|
|
2.28 |
就地一次仪表、元件 On site instruments and components |
1 |
|
|
2.29 |
振动监测 Vibration Monitoring |
3 |
Shinkawa/ANRUO |
|
2.30 |
Modbus协议RS485接口 Modbus protocol RS485 interface |
1 |
|
